Overall Height 143.99 mm (5.669 in)

Largest OD 107.01 mm (4.213 in)

Seam OD 110.01 mm (4.331 in)

Gasket OD 91.01 mm (3.583 in)

GASKET INSIDE DIAMETER 80.49 mm (3.169 in)

Thread Size 7/8-14 UNF-2B

Standpipe NO

EFFICIENCY, TWA BY SAE J 1858 98 % (98 %)

MICRON RATING BY SAE J 1858 5 micron (5 micron)

JOHN DEERE RE506428

Cross Reference:BALDWIN BF7717;DONALDSON P551773;NAPA 3720;WIX 33720

Primary Applications::BALDWIN BF7717;JOHN DEERE RE502204;JOHN DEERE RE506428;NAPA 3720;WIX 33720;DONALDSON P551773
