Overall Height 170.41 mm (6.709 in)

Largest OD 128.93 mm (5.076 in)

Seam OD 128.93 mm (5.076 in)

Thread Size 1 1/2-16 UN-2B

Standpipe NO

ADBV null

BPV Setting 0 kPa (0 PSI)

TWA MICRON @ BETA=2 14 micron (14 micron)

TWA MICRON @ BETA=20 28 micron (28 micron)

TWA MICRON @ BETA=200 0 micron (0 micron)

TWA MICRON @ BETA=75 36 micron (36 micron)

STAUFF SF6710

ZINGA SE10

ZINGA SE10P

Cross Reference:BALDWIN BT-387;DONALDSON HFP55-0387;FRAM CA401CV1

Primary Applications::AGCO L080031;BALDWIN BT-387;CHAMP LFH4988;CAN-FLO RSE50-25N;CAN-FLO RSE-50-51-25;CO-OP PL436;DELAWARE MANITOU DMS511BN;DONALDSON P16-6792;FAIREY ARLON A0805526ZB;FAIREY ARLON FA57-10
