Overall Height 294.26 mm (11.585 in)

Largest OD 119.89 mm (4.72 in)

Seam OD 121.67 mm (4.79 in)

Gasket OD 85.09 mm (3.35 in)

GASKET INSIDE DIAMETER 75.95 mm (2.99 in)

Thread Size 1 3/4-12 UN-2B

Standpipe NO

ADBV null

BPV Setting 0 kPa (0 PSI)

TWA MICRON @ BETA=2 5 micron (5 micron)

TWA MICRON @ BETA=20 10 micron (10 micron)

TWA MICRON @ BETA=200 15 micron (15 micron)

TWA MICRON @ BETA=75 13 micron (13 micron)

CASE N9086

DONALDSON P165659

Cross Reference:BALDWIN BT8313;DONALDSON P16-5659;FRAM P7084;NAPA 1731;PUROLATOR H55026;WIX 51731

Primary Applications::BALDWIN BT8874-MPG;BALDWIN BT8879MPG;BIG A 92731;CARQUEST 85731;CASE A-49386;CASE N-9086;CASE CASE IH 76094176;DONALDSON P16-5659;DONALDSON P17-5925;DONALDSON P17-9518
