Overall Height 146.94 mm (5.785 in)

Largest OD 93.22 mm (3.67 in)

Seam OD 93.78 mm (3.692 in)

Gasket OD 71.88 mm (2.83 in)

GASKET INSIDE DIAMETER 62.48 mm (2.46 in)

Thread Size 1 1/8-16 UN-2B

Standpipe NO

ADBV null

BPV Setting 0 kPa (0 PSI)

TWA MICRON @ BETA=2 8 micron (8 micron)

TWA MICRON @ BETA=20 18 micron (18 micron)

TWA MICRON @ BETA=200 0 micron (0 micron)

TWA MICRON @ BETA=75 25 micron (25 micron)

CESSNA 62200AF

VICKERS 350577

Cross Reference:BALDWIN BT-453;DONALDSON HFP55-6005;NAPA 1663;PUROLATOR 85261;WIX 42820

Primary Applications::BALDWIN BT-453;BIG A 2077;CARQUEST 85633;CARQUEST 85663;CIM-TEK 70123;CESSNA 62200-AF;CESSNA 62200-B;DONALDSON HFP55-6005;DONALDSON P77-9654;FIAT-ALLIS 77033616
